Ultra-thin IR Infrared Remote Controller For Arduino Intelligent Car SCM Learning Board Remote Control
CR2025 environmental protection button batteries required.
Working Distance: more than 8 m ( effected by the surrounding environment, the receiver sensitivity etc )
Effective Angle: 60 degrees
Surface materials: 0.125 mmPET stick, With effective life : 20000 times.
Stable quality, cost-effective
Static current 3-5 uA, dynamic current 3-5 mA
1 X remote controller
1. the standard ATMEL ISP10 converted into standard ISP6
2. used to AT89S5x series microcontroller download interface switching
1 X 10PIN to 6PIN ISP Adapter Board
Chip lm393 compared the resistor value, when there is an imbalance, the chip will control one motor to stop, while other motor accelerate rotation, in this case, the car can correct direction. The whole process is closed-loop control, so it can be quickly controleed
1 x lm393 voltage comparator
1 X 8P IC Socket
2 X 100uf capacitor
2 X 10K resistor
2 X 3.3K ohms color ring resisotr
2 x 10K resistor
4 x 51 ohm resistor
2 X 1K ohm resistor/
2 X 10 ohm resistor
2 X CDS5 photoresistor
2 X 3MM led
2 x 5MM LED
2 x 8550 TRIODE
1 x Switch
2 X Motor
6 X Wheel
1 X AA battery case
Several screws and wires
The WiiChuck Adapter is a small PCB that is designed to be inserted into the connector of a Nintendo Wii Nunchuck to provide access to all 4 wires of the remote. The power, ground and two-wire interface of the Nunchuck are all broken out to a 4-pin 0.1" pitch header. Compared with standard WiiChuck, the DFRobot WiiChuck has extra 4 pins which allow you connect it to two devices.
The Wii Nunchuck is loaded with features -- a 2-axis joystick,
two buttons and a 3 axis ±2g accelerometer -- and any device capable of I2C can communicate with it! The WiiChuck allows you to interface with the Nunchuck without making a mess and cutting the wires.
