Camera & Gimbals
X-CAM A10-3H 3 Axis 360Deg Rotation GoPro Gimbal With A/V Link
close

The X-CAM A10-3H Gimbal it at the top of the list when it comes to gimbals, the A10 has True continuous rotation 3-Axis ability with A/V Video link transfer. Full control over Roll, Tilt, Yaw, Mode and Zero home. And charging with A/V out transfer for the GoPro hero camera

The X-CAM A10-3H Gimbal it at the top of the list when it comes to gimbals, the A10 has True continuous rotation 3-Axis ability with A/V Video link transfer. Full control over Roll, Tilt, Yaw, Mode and Zero home. And charging with A/V out transfer for the GoPro hero camera.

There are a lot of 3 Axis gimbals on the market, but only a few that use a slipper for true 360Deg continues rotation and also transfers the A/V output from the GoPro to the top controller for VTX use. The A/V line also powers/charges the GoPro. Another key feature on the X-CAM is its ability to go to zero or home using referencing sensors, this is great for when transitioning from a yaw control to a forward flight mode the gimbal will auto go to the front position.

The A10 uses an advanced method of vibration control and mounting and is a full CNC aluminum frame design with integrated motors for a light 280g weight.

If you’re serious about some aerial Photography with a GoPro this is the gimbal for you

Features:
• Continuous 360deg rotation
• A/V transfer cable with power
• 5 chs of adjustment over Sbus
• Sbus and PPM support
• Home sensors
• GUI and Upgrade ability
• Wide input voltage range
• Aluminum construction

Specs:
Weight:  280g ( without GOPRO )
Stabilization frequency:  5200Hz
Input voltage:  7.4v ~ 16.8v ( 2S ~ 4S Lipo )
Tilt travel:  +-90 degree; Roll travel:  +-45 degree
YAW travel:  360 degrees unlimited rotation

25mW-200mW 1200TVL 48Ch AV Camera with Transmitter
close

Description:
Item name:JJA-TCYH42
Frequency: 5.8GHz 6 bands 48 channels
Transmission power:25mW/200mW Switchable
Working voltage:3.3-5.5V
Working current:t350mA-550mA/5V
resolution: 1200TVL
Imaging device:1/4 CMOS
Field of view: 150°-170°
Signal system:PAL/NTSC switchable
Effective pixels:1280H*1024V
Minimum illumination:0.001LUX/F1.2
Contrast:adjustable
Working temperature:-10°C-50°C
Weight:4.8G
Volume:15*23*9.5mm

Features:
1. Limit size and weight
2. Easy installation for racing drone
3. Six bands 48 channels with Raceband

Ultra HD 4K SJ9000s Camera (3840x2160) Black Color
close

Item  Ultra HD 4K SJ9000 WIFI Sport DV 2" LCD Novatek 96660 170 Degree Wide Angle FPV 30M Waterproof Action Video Camera Car DVR Colour  8 colors: Black/White/Silver/Yellow/Blue/Pink/Gold/Red WaterPoof Method  need waterproof case WaterPoof shell  Need Waterproof Depth  30M DSP  Novatek 96660 COMS Sensor  Sony IMX117 FOV 6G 170º Ultra Wide Angle Fish-Eye Focus  12cm~infinite Audio Input  Microphone HDMI output Yes USB interface  USB2.0, 5 Pin USB Storage  TF Card (Up to 64GB) LCD  2.0 Inch LTPS LCD, 320*240 Battery 3.7V 900mAh li-ion rechargeable battery Working Time  <120mins Dimension  59mm*41mm*24.5mm Package Weight  532g Package Dimension  26.7cm*16.2cm*6cm WIFI Control  Yes Video Output 4k(3840*2160) 24 fps/2.7k 30 fps/1920*1080P 60fps/1280*720p 120 fps MOV @ H.264 Video Format  MOV Video Recording  Loop recording Effective Pixels  16M/12M/8M/5M/2M Image Format  JPEG Audio  WAV(Bitrate:176kbps) Burst  3 photos per second Playback Support Shooting Mode  Single Shot / Self-timer / Continuous Shooting Time lapse 2sec,3sec,5sec,10sec,20sec,30sec,60sec Data Stamp Auto White Balance  Auto EV Compensation +-2.0 ~ +-0.3 Shutter Control  Electronic PC Camera Support Rotate 180° Support Weight  44g(without batteries),58g with batteries Accessories waterproof case, waterproof case bracket, waterproof case clip,bike bracket multifunction clip, camera clip, helmet seat, bandages 3M stickers, USB cable,manual etc. Applications Extreme Sports, Outdoor Sport Activities,Bicycle,Car DVR, Diving,Home security etc Operation system  Windows98/me/XP/vista/7 MacOS/Linux OSD language English, French, Italian, Russian, Spanish, Traditional Chinese Korean, Japanese,
Portuguese, German, Simplified Chinese Dutch, Hungarian, Polish (optional)

X-CAM Sight 2, 2-Axis Stabilizer for Smart Phone
close

The multi-angle intelligent stabilization system takes care of any unwanted movement, leaving you to concentrate on capturing the action!
The Sight2 is so compact that it really is a take-anywhere accessory for your smartphone and with up to 5 hours working duration from a single charge, you can be sure of being able to grab as much action as your camera is capable of.

For simplicity in use, the Sight2 features Bluetooth connectivity that allows you to control your phone camera functions from the easy to reach thumb wheel on the handle. This control enables up to 45° control each way in pitch (tilt) while pressing it activates the phone shutter function for taking still photographs or start/stop video recording.

Up your game with the X-CAM Sight2 handheld gimbal to produce rock-steady video from your phone!

  • Compatibility: suitable for smartphone less than or equal 5.5 inches of IOS ou Android system. Tow pads provided to help to stabilize the mobile less than 5.5 inches
  • Long working hours: Built-in 1000mAH lithium polymer battery, can be used continuously for 2-5 hours (varies according to the weight of your mobile), allow you to freely record every moment of your life
  • Practice: handheld stabilizer with small size (15*5*5cm) and light weight (189g) allow you to take it to anywhere; moreover the carrying pouch included makes the pack and the transport safer and more convenient

Features:
• Multi-angle intelligent stabilization system
• Manual neutral angle adjustment
• Bluetooth connectivity for total control
• Fits most phones up to 5.5" screen size
• Easy to see LED indicator light
• Pocket sized

Specs:
Compatible phones: iPhone 6 Plus/6s/5s/4s and other smartphones with
Pitch range: ±175°
Horizontal range: ±55°
Pitch axis control: ± 45°
Bluetooth: Low consumption International Bluetooth 4.0 standard
Battery: 1000mAh LiPo
Charging time: 2-3 hours
Maximum power: <= 10w
Working duration: 2-5 hours (depending on phone weight)
Material: Polycarbonate/ABS
Dimensions: 150 x 48 x 54mm
Weight: 189g

Included:
X-CAM Sight2 Handheld Gimbal
Allen wrench
USB lead
Self-adhesive pads
Case
Manual

RunCam Swift Mini FPV Camera with 2.8mm Lens (IR Blocked, Orange)
close

Model RunCam Swift
Image Sensor 1/3 SONY Super HAD II CCD
Horizontal Resolution 600TVL
Lens 2.8mm
Signal System PAL/NTSC
OSD Set YES
S/N Ration >60dB(AGC OFF)
Electronic Shutter Speed PAL:1/50~100,000;NTSC:1/60~100,000
AutoGain Control(AGC) YES
Back light compensation(BLC) YES
Min.illumination 0.01Lux/1.2F
WDR D-WDR
DNR 2DNR
Day/Night Auto/Color/B&W
Power DC 5 to 17V
Net weight 12g
Dimensions 26mm*26mm*30mm

Package

  • 1 X camera
  • 1 X base bracket
  • 1 X hanging bracket
  • 1 X standard back cover
  • 1 X RCA video power cable
  • 1 X FPV silicone wire
  • 1 X 5D-OSD menu cable
  • 1 X screw package

User Guide available at http://www.runcam.com/download/Swift-manual.pdf

Two-axis BGC 3.0 MOS Gimbal Controller Driver Board
close

Features:
100% Brand new and high quality!
BGC 3.0 MOS Large Current 2-axis Brushless Gimbal Controller Driver
Adopts MOS tube drive, with larger current
Two-axis brushless gimbal driver
Support 2-8 series gimbal motor

Specifications:
Drive mode: MOS
Size: 5*5cm
Peak current: 10A

Package include:
1 X Two-axis brushless gimbal driver
1 X Sensor
1 X Cable



Wireless Pan Tilt IP Camera Wifi Night Vision Camera IP Network Camera CCTV WIFI P2P Onvif IP Camera
close

see features in Pictures

Camera Gimbal Tilt Mount for Bumblebee Quadcopter Frame
close

This camera gimbal tilt mount makes for stunning video recording capability with your Bumblebee Quadcopter. It included a pre-mounted metal gear mini servo which allows for tilt action.

This mount is constructed of high quality carbon fiber and features rubber grommets made of a special vibration-dampening compound which makes for superb video quality.

Specs:
Max camera width: 120mm
Max camera height: 183mm (measured at center of mount)
Weight: 101g






PRODUCT ID: 9031000023



Mini Wide Angle FPV Camera 700 TVL 3.6mm PAL
close

Specifications:
Definition: 700 TVL
Illumination: 0.5lux, 0.001lux
S/N: more than or equal to 48dB
Gama: 0.45
Focal length: 3.6mm
Frame speed: PAL 25f/s
White balance: auto
Video out: CVBS 1Vp-p
Audio out: yes
TV format: PAL
Power: 12v 1A
Voltage range: DC 5V-12V
Power consumption: 80mA, 120mA

Size: approx 1.4x1.3x1cm
Color: multicolor
Net weight: 5g

Package includes:
1x FPV Camera
1X user manaul

Head Band Strap Mount for GoPro Hero SJCAM HD Camera
close

Features:
Keeps your Gopro camera on your head safe.
Mounts can rotate 360 degree, suit for your different shooting.
Anti-skid back of the strap, making it more convenient.
Elastic strap, made of superior quality material, durable and usable.
Adjustable and compact design, meeting different requirements of the users.
Lightweight, portable, easy to take.
Compatible with Sony Action Cam HDR AS15 AS20 AS30
All Gopro Camera (HERO4 SESSION, Hero4, Hero3 plus, Hero3, Hero2)
All SJCAM Camera(SJ4000,SJ5000,SJ6000,SJ7000, ELITE, 4K,etc)
Xiaomi Yi Sports Camera

Specifications:
Color: Black
Material: Polyester + PC
Perimeter: approx.570 x 400mm/22 x 15.7 inch
Delivery size: 118 x 180mm/4.6 x 7.1 inch
Net weight: 95g
Package weight: 99g

Package Content:
1x Head strap (not include Camera)

Mini 700TVL 5V-12V 2.8mm FPV Camera with LRC Filter
close



Specifications:
Definition: 700 TVL
Illumination: 0.5lux, 0.001lux
S/N: more than or equal to 48dB
Gama: 0.45
Focal length: 2.8mm
Frame speed: PAL 25f/s
White balance: auto
Video out: CVBS 1Vp-p
Audio out: yes
TV format: PAL
Power: 12v 1A
Voltage range: DC 5V-12V
Power consumption: 80mA, 120mA
Size: approx 1.4x1.3x1cm
Color: multicolor
Net weight: 5g

FPV LC Filter for Camera
close



Compact, lightweight power supply filter with switch, helps clean up dirty DC output jitter that often causes lines in wireless video images.
The filter is an LC type that uses large value inductor and capacitor components.

Specifications:
Input: 3.3V -25V
Max. 25V input
Maximal current: 2A
Net Weight: 6g

Package includes:
1 x DC-DC LC filter

Mini HD 1000TVL CCTV FPV Camera for Quadcopter QAV210/180/250
close

Compact and simple design, ultra small size, low power consumption, good concealment, excellent stability

Specifications:
Lens focal length: 2.8mm
Singal system: PAL/NTSC system
Horizontal Articulation: 1000TVL
Min Illumination: 0.01LUX
White Balance: Auto
Video Frame Rate: PAL:967H x 582V, NTSC: 976H x 494V
Video Output: 1.0Vp-p75 ohm
Electronic Shutter: 1/50(1/60)-1/100000s
Back Light Compensation: ON/OFF
Synchronization: Inter-sync
Power input: DC12V FPV3.5-5V
Power Consumption: 70mA
Openration Tempetature: -20℃--60℃ (0%-98%)
Size: 24 x 17 x 28mm/0.9 x 0.7 x 1.1 inch
Package size: 90 x 65 x 55mm/ 3.5 x 2.6 x 2.2 inch
Net weight: 14g
Package weight: 39g

Multi-Rotor Roll/Tilt GoPro Hero 2 Camera Mount
close

Start capturing amazing aerial video with your multi-rotor frame and this roll/tilt camera mount! This mount is designed to fit twin-rail camera mount multi-rotor frames such as Bumblebee, Ideafly etc.

This camera mount offers you roll and tilt control of your on-board camera while flying. It is constructed from fiberglass and aluminum alloy offering rigidity while saving weight. The mounting points for the roll and tilt servos are pre-cut and will accommodate most mini/micro servos without modification.

All necessary hardware is included to install this mount to your frame. You will simply need to add your own mini/micro servos and camera.

Specs:
Camera Mount Max Inner Width: 82mm
Camera Mount Max Inner Height: 44mm
Weight (inc. all hardware): 85g
